m4

Created: 04 Jan 2025
Updated: 22 Aug 2025
home https://www.gnu.org/software/m4/m4.html
docs html pdf
manual 77 https://wolfram.schneider.org/bsd/7thEdManVol2/m4/m4.pdf
history https://www.gnu.org/software/m4/manual/html_node/History.html
wiki https://en.wikipedia.org/wiki/M4_(computer_language)

cli

Figure 1: m4 cli arguments
  • rlwrap compatible
  • cli is a "filter", aka takes data and instructions (stdin) and outputs transformed data (stdout)
  • -dV - set debug mode to V for full debugging

language

  • turing complete
  • no floating point support
  • no loops, only recursion
  • `' makes non-terminal symbols terminal ones
    • removed on each macro pass
  • macro names
    • recognized if appear surrounded by non-alphanumeric
    • are alphanumeric, including "_"
  • we use different quoting for each side to allow nesting
    • without needing extra escaping

variables

$0 macro name
$1 first argument or empty string
$# number of arguments
$@ all the arguments, unexpanded
$* all the arguments, expanded
shift($@) all the argument, except the first

commands/macros

  • built-in commands = 24
    • are themselves macros
  • all global, no concept of scope
    • but there is a stack of definitions
  • can function:
    • as global variables when expanded without arguments
    • as functions when arguments are provides
dnl - deletes to new line
include(`foo.m4')  # expands to content of foo.m4
sinclude(`foo.m4') # expands to content of foo.m4, silently fail on non exist
changequote([,])   # changes `' to []
changequote        # restores `'

Defining a new one

pushdef(`NAME', 20)
popdef(`NAME')
define(`NAME', 0) # = popdef + pushdef
undefine(`NAME')
  • For each macro definition, m4 creates a stack of definitions
  • name
    • begin with a letter, followed by letter, digit and underscore
    • case significant
  • value
    • always treated as text even if it is numeric
    • leading blanks that occur during argument collection are discarded
    • argument references ($1) expand immediately regarless of quoting
      • can be preventing by breaking it ($`'1)

Output Queues

divert(N)    #  switches the Output Queue, N ∈ [0,...]
divert(-1)   # -1 (invalid queue), used to throw away output
define(g,19) # discarded
divert`'     # same as divert(0)
undivert(1)  # pushes output queue 1 to output
divnum       # expands to currently active diversion

Conditional

ifdef(`foo', b)      # b if foo is defined
ifdef(`foo', b, c)   # b if foo is defined, c if not

                     # "switch", 3N+1 arguments
ifelse(comment)      # discarded argument
ifelse(a,b,c,d)      # compares a,b ... returns c if match, else d if not
ifelse(a,b,c,d,e,f,g)# compares a,b ... returns c if match, else compares d,e
ifelse(a,b,c,        # same as above, more explicit
      ifelse(d,e,f,g))

String Manipulation

len(abdcde)              # returns 6
substr(abcdef,2)         # returns "bcdef"
substr(abcdef,3,3)       # returns "def"
index(abcdef,c)          # returns 2
index(abcdef,z)          # returns -1
translit(leet,aeio,4310) # returns "l33t"
translit(leet,aeio)      # returns "lt"
regexp(abc88def,`[0-9]') # returns 3
regexp(ab77,`[0-9]',`?')
patsubst()               # find and replace
format(`%05d', `$#')

Integer Arithmetic

+ - ** / * %
<< >> ~ & ^ | # bitwise operators
> >= == != < <= && || !

eval(1 + 1) #  2
eval(-8>>1) # -4
eval(~0)    # -1
eval(6&5)   #  4
eval(3^2)   #  1
eval(1|2)   #  3

incr(100)   # 101
incr(`i')   # i + 1
decr(100)   #  99
decr(`i')   # i - 1

OS interaction

syscmd(find . -type f)         # runs without capturing/interpriting
esyscmd(hostname | tr -d '\n') # captures/interprets output
sysval                         # last command exit status
maketemp
makestemp

Debugging

dumpdef(`NAME')          # shows the definition of given macro
dumpdef(`NAME',`upcase')
debugmode(`V')           # V = full debug
defn(`NAME')             # shows macro definition
errprint(`msg')          # to stderr

codebases

snippets

dnl shift(@) removes an argument and splice it back
dnl defines different behaviour depending on how many arguments is called
define(`reverse', `ifelse(`$#',`0', ,`$#',`1',``$1'', `reverse(shift($@)), `$1'')')
define(`upcase', `translit(`$*', `a-z', `A-Z')')
define(`_capitalize`,
       `regexp(`$1', `^\(\w\)\(\w*\)',
               `upcase(`\1')`'downcase(`\2')')',
               `toSpace')
define(`PlaylistItem',` upcase($1) ')
PlaylistItem(`foo.hml')

  • self-modifyng macro

    define(`ACCEPT',`define(`ACCEPT',`Already accepted')Accepted')
ACCEPT # -> Accepted
ACCEPT # -> Already accepted

  • for loop (from mbreen.com)

    define(`for',
    `ifelse($#,0,
        ``$0'',
        `ifelse(eval($2<=$3),1,
            `pushdef(`$1',$2)$4`'popdef(`$1')$0(`$1',incr($2),$3,`$4')')')')
for(`x',1,5,`x,') # 1,2,3,4,5...

  • for each loop (from mbreen.com)

    define(`foreach',
    `ifelse(eval($#>2),1,
           `pushdef(`$1',`$3')$2`'popdef(`$1')dnl
           `'ifelse(eval($#>3),1,`$0(`$1,`$2',shift(shift(shift($@))))')')')
foreach(`X',`Open the X.',`door',`window') # Open the door. Open the window.

  • while loop (from mbreen.com)

    define(`while',
       `ifelse($#,0,``$0'',
              eval($1+0), 1, `$2`'$0($@)')')

trivia

the "xz backdoor"
